Ford Tractor Parts
Showing 1–8 of 121 results
-
1000 Ford Tractor 8-1/2” Single Stage Clutch Kit Assembly
This Is a New 8-1/2” Single Stage Clutch Kit Assembly Flywheel Step Flat The Kit Comes With 8-1/2’’ Single Stage Pressure Plate with 3 Lever 3 Spring 8-1/2’’ Woven Clutch Disc With 15/16’’ 10 Spline Hub Release Bearing OD 2.900” ID 1.771” Thickness 0.313” Pilot Bearing OD 1.102” ID 0.475” Thickness 0.313” Alignment Tool Large Spline 1-3/8” 19 Spline Small Spline 15/16” 10 Spline Pilot Diameter 0.470” $160.00 -
1120 Ford Tractor 7-1/4″ Single Stage Clutch Kit Assembly
This Is a New 7-1/4’’ Single Stage Clutch Kit Assembly The Kit Comes With 7-1/4’’ Diaphragm Pressure Plate 7-1/4’’ Woven Clutch Disc with 13/16’’ 18 Spline Hub Release Bearing ID OD 2.642’’ ID 1.496’’ Thickness .700’’ Pilot Bearing OD 1.102’’ ID 0.475’’ Thickness 0.313’’ $160.00 -
118650 8-1/2″ Dual Stage Clutch Kit
This Is a New 8-1/2’’ Dual Stage Clutch Kit Assembly The Kit Comes With 8-1/2’’ Dual Stage Pressure Plate With 1-3/8” 19 Spline Hub 8-1/2” Woven Clutch Disc with 15/16’’ 10 Spline Hub Release Bearing OD 3.450” ID 2.164” Thickness .765” Pilot Bushing OD 1.102” ID 0.475” Width 0.313” Alignment Tool Large Spline 1-3/8” 19 Spline Small Spline 15/16” 10 Spline Pilot Diameter 0.470” Flywheel Step .079” $300.00 -
1210 Ford Tractor 7-1/4″ Single Stage Clutch Kit Assembly
This Is a New 7-1/4’’ Single Stage Clutch Kit Assembly The Kit Comes With 7-1/4’’ Diaphragm Pressure Plate 7-1/4’’ Woven Clutch Disc with 13/16’’ 18 Spline Hub Release Bearing ID OD 2.642’’ ID 1.496’’ Thickness .700’’ Pilot Bearing OD 1.102’’ ID 0.475’’ Thickness 0.313’’ $160.00 -
1215 Ford Tractor 7-1/4″ Single Stage Clutch Kit Assembly
This Is a New 7-1/4’’ Single Stage Clutch Kit Assembly The Kit Comes With 7-1/4’’ Diaphragm Pressure Plate 7-1/4’’ Woven Clutch Disc with 13/16’’ 18 Spline Hub Release Bearing ID OD 2.642’’ ID 1.496’’ Thickness .700’’ Pilot Bearing OD 1.102’’ ID 0.475’’ Thickness 0.313’’ $160.00 -
1220 Ford Tractor 7-1/4″ Single Stage Clutch Kit Assembly
This Is a New 7-1/4” Single Stage Clutch Kit Assembly The Kit Comes With 7-1/4” Diaphragm Pressure Plate 7-1/4” Woven Clutch Disc With 15/16” 10 Spline Hub Release Bearing OD 2.642” ID 1.496” Thickness .640” Pilot Bushing OD 1.102” ID 0.475” Thickness 0.313” Alignment Tool Large Spline 1-3/8” 19 Spline Small Spline 15/16” 10 Spline Pilot Diameter 0.468” Flywheel Step Flat $227.00 -
1220 Ford Tractor 7-1/4″ Single Stage Clutch Kit Assembly
This Is a New 7-1/4’’ Single Stage Clutch Kit Assembly The Kit Comes With 7-1/4’’ Diaphragm Pressure Plate 7-1/4’’ Woven Clutch Disc with 13/16’’ 18 Spline Hub Release Bearing ID OD 2.642’’ ID 1.496’’ Thickness .700’’ Pilot Bearing OD 1.102’’ ID 0.475’’ Thickness 0.313’’ $160.00 -
1300 Ford Tractor 7-1/4″ Single Stage Clutch Kit Assembly
This Is a New 7-1/4” Single Stage Clutch Kit Assembly The Kit Comes With 7-1/4” Diaphragm Pressure Plate 7-1/4” Woven Clutch Disc With 15/16” 10 Spline Hub Release Bearing OD 2.642” ID 1.496” Thickness .640” Pilot Bushing OD 1.102” ID 0.475” Thickness 0.313” Alignment Tool Large Spline 1-3/8” 19 Spline Small Spline 15/16” 10 Spline Pilot Diameter 0.468” Flywheel Step Flat $227.00
